| Specification (AWG) | Conductor | PVC Insulation | |||||||
| Dia.(mm) | Structure | Dia.(mm) | Nominal Thickness (mm) | Dia(mm) | |||||
| 1 | × | 18 | 0.254 | 16 | / | 0.254 | 1.16 | 0.76 | 2.68 |
| 1 | × | 16 | 0.297 | 19 | / | 0.297 | 1.49 | 0.76 | 3.01 |
| 1 | × | 16 | 0.254 | 26 | / | 0.254 | 1.49 | 0.76 | 3.01 |
| 1 | × | 14 | 0.370 | 19 | / | 0.370 | 1.85 | 0.76 | 3.37 |
| 1 | × | 14 | 0.254 | 41 | / | 0.254 | 1.87 | 0.76 | 3.39 |
| 1 | × | 14 | 0.160 | 104 | / | 0.160 | 1.88 | 0.76 | 3.4 |
| 1 | × | 12 | 0.470 | 19 | / | 0.470 | 2.35 | 0.76 | 3.87 |
| 1 | × | 12 | 0.254 | 65 | / | 0.254 | 2.36 | 0.76 | 3.88 |
| 1 | × | 10 | 0.590 | 19 | / | 0.590 | 2.95 | 0.76 | 4.47 |
| 1 | × | 10 | 0.254 | 104 | / | 0.254 | 2.99 | 0.76 | 4.51 |
| 1 | × | 10 | 0.511 | 26 | / | 0.511 | 2.99 | 0.76 | 4.51 |
| 1 | × | 8 | 0.750 | 19 | / | 0.750 | 3.75 | 1.14 | 6.03 |
| 1 | × | 8 | 0.511 | 41 | / | 0.511 | 3.77 | 1.14 | 6.05 |
| 1 | × | 6 | 0.940 | 19 | / | 0.940 | 4.7 | 1.52 | 7.74 |
| 1 | × | 6 | 0.511 | 65 | / | 0.511 | 4.75 | 1.52 | 7.79 |
