RHZ1 cables are medium voltage cables used in various power distribution networks, including for large industrial facilities, power plants, transformer stations, and renewable energy projects like wind and solar farms. Their applications are suited for underground installations in tunnels and trenches, or direct burial, where they offer fire safety and resistance to moisture due to their halogen-free polyolefin sheath. Different versions like RHZ1-OL and RHZ1-2OL provide enhanced water protection, while AS variants offer fire-retardant properties for critical areas.

Maximum service temperature: 90ºC.
Maximum short-circuit temperature: 250ºC (max. 5 s).
Minimum service temperature: -15ºC


Halogen free: based on IEC 50267.
Flame non-propagation based on IEC 60332-1.
Halogen free: based on IEC 50267.
Low smoke emission based on IEC 61034.
Minimum bending radius: x15 cable diameter.
Abrasion-resistant.
Tear-resistant.
UV Resistant



IEC 60502-2
